Duplex Filter Strainer

The strainer is a filtering element incorporated in the pipe line. It is called a ‘Y’ Type, ‘Basket’ Type or ‘T’ Type strainer because of its shape. Inside the strainer is a mesh, which blocks any suspended impurities that the fluid has and is collected in the mesh. During maintenance the mesh can be removed and cleaned of the impurities.

Design Conforms to ASME B16.10 & ASTM Section VIII-Div.2

Specification :

• Material of Wetted Parts CI/ASTM A216 Gr WCB/ASTMA351CF
  8/ASTMA351CF8M/MS/CS/SS304/SS304L/SS316/SS316L/PP & HDPE
• Filter Elements SS316/SS304/BRASS
• Mesh Size 5 to 500 microns
• Temperature Up to 600°C
• Pressure Up to 60 Kg/CM²
• Line Size Up to 1200 NB depening upon the type
• Connection Flanged to ASA/BS/DIN/JIS/Screwed BSP/NPT/Butt Weld

Y Type Strainer Flanged End

Y and t-type strainer flanged end

Basket Type Strainer

Basket Type

Duplex Filter Strainer

Duplex Filter
