Displacer Level Indicator Transmitter DLI-EXCG
Product Code : DLI / DLI-EXCGDLI displacer level gauge is featured by stable accuracy, good linearization, easy installation, field indication, remote output 4-20mA. Its operation principle is A displacer immersed in the measured medium, as liquid level changes, the displacer will move by the buoyancy force thus makes the change of spring length which connecting with displacer and then the spring spurs, magnet steel, so that the magnet field close to Hall effect sensor will be changed. This change is proportional to buoyancy force (liquid level).
Specification:
| Power Supply | : | 2VDC | Field indication | : | needle Indication |
|---|---|---|---|---|---|
| Nominal Pressure | : | 2.5 bar to 320 bar | Medium density | : | >- 0.4g/cm³ |
| Load resistance | : | 650 | Humidity | : | 0~99% |
| Housing material | : | Dai Cast Aluminimum | Output | : | 4~ 20 mA+HART |
| Accuracy | : | 0.5% FS | Medium temperature | : | max 450 °C |
| Electrical interface | : | M20x1.5, or on request | Ambient temperature | : | +0 ~ 60° C |
| Flange standard | : | Customize | Enclosure | : | IP65 |
