Spacification

• Name Standard Rotary Paddle Level Switch High Teperature Rotary Paddle Level Switch Rotary Paddle Level Switch
• Model (1) SD-R2-10F
  (2) SD-R2-10S
  …. (1) SD-R2-20F-H
  (2) SD-R2-20F-T
  (3) SD-R2-20F (1) SD-R2-40F
  (2) SD-R2-10F
  (3) SD-R2-30F
• Power Supply 220VAC, Optional(110VAC, ,24VAC,24VDC) 220VAC, Optional(110VAC, ,24VAC,24VDC) 220VAC, Optional(110VAC, ,24VAC,24VDC)
• Contact Capacity 220VAC 5A, DPDT 220VAC 5A, DPDT 220VAC 5A, DPDT
• Medium Temperature -10 °C~80°C Max 200°C~800°C -10 °C~80°C
• Power 3W 3W 3W
• Rotating speed of Paddle 1RPM 1RPM 1RPM
• Material of Paddle SS304 SS304 SS304
• Paddle Size 40x100mm 65x100mm 40x100mm
• Electrical Connection M20x1.5 M20x1.5 M20x1.5
• Specific Gravity of Material >0.4g/cm3 >0.4g/cm3 >0.4g/cm3
• Installation Method horizontal or vertical installation horizontal or vertical installation horizontal or vertical installation
