Double Window Sight Glass with Flapper

A sight Flow Indicator is a device which is inserted in a run of pipe to observe the flow of fluid in the pipe. To enhance the visibility of the flow, spinner is often incorporated in the flow stream so that fluid impinging on the spinner vanes cause it to turn.

Specification :

• Design Temperature Up to 200°C depending upon the type
• Design Pressure Up to 20 Kg/cm² depending upon the type
• Line Size Up to 400 NB depending upon the type
• Material of wetted parts CI/ASTMA216GrWCB/ASTMA351CF8/ASTMA351CF8M/MS/CS/SS304/SS304L/SS316 L and PP/HDPE/PVDF/PFA/PTFE Lined
• Connection Flanged to ASA/ABS/DIN/JIS/Screwed BSP/NPT/Butt Weld

Full view and full view with indicating ball sight glass

Full View And Full View With Indicating Ball Sight Glass

Double Window Sight Glass with Flapper

Double Window And Double Window With Flapper Sight Glass

Full View Sight Glass Tri-Clover Connection

Full View Sight Glass Tri-Clover Connection
