Radar Level Indicator Transmitter

Introduction

• Suitable for Medium Liquid, especially for corrosive liquid
• Measuring Range20m
• Level Display Four LCD /Can be programmed
• Aerials The Rod Antenna (PTFE)
• Frequency 6 GHz
• Temperature (-40 ~ 180)°C
• Measurement Precision ± 10mm
• Process Pressure (-1.0 ~ 4) MPa
• The Signal Output (4 ~ 20) mA+HART
• Power Source Two-wire (DC24V) Four-wire(DC24V/AC220V)
• Repeatability ± 1mm
• Shell Aluminum/Plastic
• Connection Flange (optional)
• Protection Grade Explosion-Proof Exia IIC T6 Ga/Exd ia IIC T6 Gb

Introduction

• Suitable for Medium Liquid, slightly corrosive liquid
• Level Display Four LCD /Can be programmed
• Aerials The Rod Antenna( PP/PTFE )
• Frequency 6 GHz
• Temperature (-40 ~ 130)°C
• Measurement Precision ± 10mm
• Process Pressure (-0.1 ~ 0.3) MPa
• The Signal Output (4 ~ 20) mA+HART
• Power SourceTwo-wire (DC24V) Four-wire(DC24V/AC220V)
• Repeatability ± 1mm
• Shell Aluminum /Plastic
• Connection Flange (optional) / Thread
• Protection Grade Explosion-Proof Exia IIC T6 Ga/ Exd ia IIC T6 Gb

Side Mounted Magnetic Level Indicator (MLI 2200 Series)

Side Mounted Magnetic Level Indicator Transmitter

Reflex Level Indicator (RTI 2000 Series)

Reflex Level

Side Mounted Magnetic Level Indicator (MLI 2200 Series)

Side Mounted Magnetic Level Indicator Transmitter and Level Switches
